Basic Vehicle Information | |
Announcement Model | EQ5041XXY3BDDAC |
Vehicle Type | Box Van Truck |
Drive Configuration | 4×2 (2 front steering wheels + 2 rear driving wheels) |
Wheelbase | 2800 mm |
Cargo Box Length Class | 3.8 m |
Engine Model | Quanchai 4A2-88C50 |
Transmission Model | Mengwo 5A85 |
Rear Axle Ratio | 4.875 |
Overall Vehicle Length | 5.55 m |
Overall Vehicle Width | 2 m |
Overall Vehicle Height | 2.75 m |
Front Track Width | 1450 mm |
Rear Track Width | 1470 mm |
Curb Weight | 2.465 tons (2465 kg) |
Rated Payload Capacity | 1.9 tons (1900 kg) |
Gross Vehicle Weight (GVW) | 4.495 tons (4495 kg) |
Maximum Speed | 103 km/h |
Place of Origin | Xiangyang, Hubei (China) |
Tonnage Class | Light Truck |
Approach Angle | 21° |
Departure Angle | 15° |
Target Market Segment | Urban Distribution |
Remarks | Equipped with LCD instrument cluster and MP3; Gear shifting: Dual-cone synchronizer |
Front Overhang/Rear Overhang | 1.215 m / 1.535 m |
Version | Not Specified |
License Plate Type | Blue License Plate (Compliant with China’s light-duty vehicle license standards) |
Energy Type | Diesel |
Engine Parameters | |
Engine Brand | Quanchai |
Engine Model | Quanchai 4A2-88C50 |
Engine Series | Quanchai 485 Series |
Number of Cylinders | 4 Cylinders |
Fuel Type | Diesel |
Cylinder Arrangement | In-line |
Displacement | 2.27 L |
Emission Standard | China National V Emission |
Maximum Output Power | 65 kW |
Maximum Horsepower | 88 HP |
Maximum Torque | 240 N·m |
Maximum Torque Speed | 2000 rpm |
Rated Engine Speed | 3200 rpm |
Engine Form | Not Specified |
Transmission Parameters | |
Transmission Model | Mengwo 5A85 |
Transmission Brand | Mengwo |
Shifting Mode | Manual |
Number of Forward Gears | 5 Gears |
Number of Reverse Gears | 1 Gear |
Cargo Box Parameters | |
Cargo Box Type | Box-type (Enclosed van structure for cargo protection) |
Cargo Box Length | 3.8 m |
Cargo Box Width | 1.88 m |
Cargo Box Height | 1.75 m |
