Aircraft Refueler
This aircraft refueler provides stable, clean and high-speed aviation fuel refueling service. The tank body adopts high-quality carbon steel or stainless steel. It comes with professional refueling pump, filtering system and safety control devices. Chassis can be chosen from ISUZU, SHACMAN, HOWO, DONGFENG, JIEFANG. Fully customizable based on client requirements.
[Vehicle Technical Parameters] | |
Product Name | Aircraft refueling truck |
Total mass (kg) | 45000/49000 |
Curb Weight(Kg) | 17000/19500 |
Boundary Dimension(mm) | 13000/17500x2650x3480/3600 |
Tank Volume(m³) | 35-60 |
Tank Thickness(mm) | 6 |
Tank Body Material | Carbon steel/Aluminum alloy/Stainless |
Compartment | 2-6 As Customer Need |
Operating Ambient Temperature(°C) | -20~50 |
Manhole Cover | European Standard |
Emergency Shut Off Valve | Include |
Oil Gas Recovery Unit | / |
Anti-Overflow Alarm Device | Include |
Fuel Loading method | Bottom Filling |
Gear Oil Pump Flow(L/min) | 2200-2600 |
Toolbox | As Required |
[Chassis Technical Parameters] | |
Chassis Brand | DONGFEGN |
Drive Form | 8*4 LHD RHD Optional |
Steering Device | Power steering ,hydraulic steering with power assistance |
Wheelbase(mm) | 2050+4000+1400 |
Engine Brand | dCi420-51 |
Power(kw) | 308 |
Horse Power(HP) | 420 |
Fuel Type | Diesel |
Emission standard | Euro II, Euro III, Euro IV, Euro V, Euro VI available |
Gearbox | 12 Speed Manual |
Front/Rear Axle(t) | 7.5/15 |
Suspension | Multi Leaf Springs |
Brake System | Front/Rear Drum Full Air Braking |
Tires Spec | 12.00R20 |
Cab Configuration | air conditioning, radio, MP3 and USB port,A |
Others | 2 sets of 4kg extinguishers 1 set of static belt Level gauge Flow meter Colors and designs are customized to your specifications. |
