Vehicle Model

EHY5161GJBD5AB

Vehicle Brand

HUAYI

Overall dimensions

7050×2380×3380mm

Curb weight

7955kg

Loading capacity

5m3

Chassis model

DYQ1161D5AA

Chassis brand

DAYUN TRUCK

Overall dimensions

6240x2370x3050mm

Wheel base

3600mm

Front/rear wheel track

1940/1860mm

Front/rear suspension

1240/1400mm

Approach/departure angle

25/29°

Maximum speed

90km/h

Chassis Manufacturer

DAYUN AUTOMIBILE CO.,LTD

Cab

Configuration

allowable 3 passengers

Color

white,other color is optional

Engine

Model

YC4S140-50

Emission

Euro 5

Type

4 cylinders,in-line,water-cooled, turbo inter-cooling, diesel engine

Rated power

140hp

Displacement

3767ml

Bore x stroke

102×115mm

Manufacturer

Guangxi Yuchai Machinery Group Co.,Ltd

Tire

Size

9.00-20 nylon tire

Number

6+1 nos

Brake

Air brake

Fuel tank

120L

Rear axle

10T rear axle

Drive form

4X2

Rated voltage

24V, DC

Transmissions

6 speed forward 1 reverse

Steering device

Power assisted steering

Steering wheel

Left hand drive

Selective configuration

If there is a slight change in the chassis parameters above,please take the actual product as the standard

Mixing capacity(m³)

5

Color and Logo

Optional

Feeding speed (m³/min)

≥3

Discharge speed(m³/min)

≥2

Discharge residual rate

≤0.5%

Slump scope(mm)

50-210

Water tank capacity(L)

300

Water pressure(Mpa)

0.35-0.38

Tank material

5mm alloy steel

Tank front head

6mm alloy steel

Reducer

Keyi

Hydraulic motor

DALI

Hydraulic pump

Changyuan

Radiator

ZHENGHUA

Standard configuration

Less than 7m3:chassis,sub frame,mixer tank(main tank 5mm alloy steel wear resistant material,front tank head 6mm alloy steel wear resistant material),domestic reducer,hydraulic pump,hydraulic motor,radiator,water tank,cleaning hose,feed port, discharge port,climbing ladder,air pressure water supply device.

Selective configuration

1,American SALI56 hydraulicy pump, SALI63 hydraulic motor

2,Italy P071 hydraulic pump, M063 hydraulic motor

3,A full set of imported parts (ZF3301 reducer)
