Sinotruk Sitrak 20 Ton 25 Ton Hook Lift Garbage Truck 8x4 Heavy Roll Off Garbage Truck Diesel Waste

Inquiry now

[VehicleTechnical Parameters]
Product Name	Hook Lift Garbage Truck
Kerb Weight (Kg)	11520
Overall Dimensions (mm)	8470×2520×3120
Lifting Capacity(Kg)	20000-25000
Big Arm Structure	Integrated Molding
Working Environment Temperature （℃）	-20~45
Operating Mode	Automatic+Manual
Dumping Angle of Garbage Bin（°）	70
Garbage Bin Capacity(m³)	20
Trash Container Thickness（mm）	5 Side 6 Bottom
Garbage Bin Size(mm)	6200×2500×1700
Material of Garbage Bin	Q235 Carbon Steel
Garbage Bin Coating Process	Baking Varnish
Max Passengers Allowed	2
[Chassis Technical Parameters]
Brand Name	Sinotruk
Brake	Air Brake/Oil Brake
Fuel Type	Diesel
Engine Power（kw）	228
Front Axle/Rear Axle (t)	5/Double 10
Gearbox Model	10-Speed Manual
Number of Axles	3
Wheelbase (mm)	4300+1350
Number of Tires	10
Tire Size	11.00R20
